XIN6011
• 12 Volt, B-Circuit, S(AS)-L(IG)-AM(LI) Terminals
• Denso IR/IF Alternators
• Notes - S-L-AM on OE alternator label.,AS-IG-LI terminal functions. Not a PCM regulator
• Replaces - DENSO 126600-0110
-
XIN6015
• 12 Volt, B-Circuit, IG-S-L-M(FR) Terminals, 14.2 Vset
• Denso IR/IF Alternators
• Notes - Standard lamp function - no output.
• Replaces - DENSO 0150, 126600-0150
-
XIN6300
• 12 Volt, B-Circuit, IG-S-L-FR Terminals, 14.1 Vset
• Denso IR/IF Alternators
• Ignition activated
• Notes - Standard lamp function - no output.,Without LRC.,Must have 1K Resistor between the FR and IG terminals.
• Replaces - DENSO 126600-3000
-
XIN6301
• 12 Volt, B-Circuit, IG-S-L-M(FR) Terminals, 14.1 Vset, 6 sec. LRC
• Denso IR/IF Alternators
• Full range LRC
• Notes - Standard lamp function - no output.
• Replaces - DENSO 126600-3010, TOYOTA 27700-20090, 27700-20100
-
XIN6302
• 12 Volt, B-Circuit, IG-RLO-L-M Terminals, 14.1 Vset, w/ LRC
• Denso IR/IF Alternators
• Ignition activated
• Replaces - DENSO 126600-3020, 126600-3320, 3020
