XIN6601
• 12 Volt, A-Circuit, BVS-RC-LI Terminals, 14.0 Vset
• Denso IR/IF Alternators
• Notes - Regulation voltage controlled by vehicle PCM.,Vehicle lamp controlled by vehicle PCM.
• Replaces - DENSO 126600-3460, 126600-7140
-
XIN9218
• 12 Volt, A-Circuit, NF-IG-L Terminals, 14.5 Vset
• Denso IR/IF Alternators
• Ignition activated
• Notes - NF = no function.,Active lamp function - with output.,Without LRC
• Replaces - DENSO 126000-2180, 126000-2181, ISUZU 8-97124-161-0
-
XIN9252
• 12 Volt, A-Circuit, 14.2 Vset
• Denso Brushless IR/EF Alternators
• Replaces - DENSO 126000-2520
-
XIN9254
• 24 Volt, A-Circuit, NF-IG-L Terminals, 27.9 Vset
• Denso 24V Brushless IR/EF Alternators
• Replaces - CAT 185-2648, DENSO 126000-2540
-
XIN452
VRH200548A - MOBILETRON
Voltage Regulator NIPPONDENSO 14V 63.5mm
Replaces TRANSPO IN452
Replaces :
Denso 126000-1920. 126000-1970. 126000-1971. 126000-1977. 126000-2680. 126000-2740. 126000-3060. 126000-3530
Suzuki 32500-60G10
Application in Alternators :
Denso 101211-055. 101211-072. 101211-520. 102211-502. 102211-507. 102211-528
Suzuki 31400-60G10. 31400-60G11. 31400-60G12. 31400-60G13. 31400-77E20. 31400-77E21. 31400-77E22. 31400-77E22
