XIN6329
• 12 Volt, B-Circuit, F-L Terminals, 13.8 Vset
• Denso IR/IF Alternators
• Field short-circuit protection
• Notes - L is not traditional lamp terminal.,Vset controlled by vehicle RVC system
• Replaces - DENSO 126600-3290, GC33290
-
XIN6335
• 12 Volt, B-Circuit, IG-C-L-FR Terminals, 14.5 Vset, w/ LRC
• Denso IR/IF Alternators
• Notes - Standard lamp function - no output.
• Replaces - DENSO 122600-0140, 126600-0140, 126600-3200, 126600-3350, HONDA 31150-RAA-A010M, 31150-RAA-A011M, 31150-RAA-A030M
-
XIN6343
• 12 Volt, B-Circuit, AS-RC-LI Terminals, 13.5 Vset (default)
• Denso IR/IF Alternators
• Notes - PCM controlled regulation voltage
• Replaces - DENSO 126600-3430, 126600-3640
-
XIN6349
• 12 Volt, B-Circuit, LI-RC-BVS Terminals, 14.0 Vset (default)
• Denso IR/IF Alternators
• Short-circuit protection: field
• Notes - PCM controlled regulation voltage
• Replaces - DENSO 126600-3490
-
XIN6365
• 12 Volt, B-Circuit, IG-C-L-FR Terminals
• Denso IR/IF Alternators
• Volt Set 14.35V
• Replaces - DENSO 126600-3650
