XIN6302
• 12 Volt, B-Circuit, IG-RLO-L-M Terminals, 14.1 Vset, w/ LRC
• Denso IR/IF Alternators
• Ignition activated
• Replaces - DENSO 126600-3020, 126600-3320, 3020
-
XIN6308
• 12 Volt, B-Circuit, NC-NC-L-FR Terminals, 14.4 Vset
• Denso IR/IF Alternators
• Lamp activated
• Notes - NC = no connection,Standard lamp function - no output.
• Replaces - DENSO 126600-3080
-
XIN6315
• 12 Volt, B-Circuit, IG-C-L-FR Terminals, 14.35 Vset
• Denso IR/IF Alternators
• Ignition activated
• Notes - Standard lamp function - no output.
• Replaces - DENSO 126600-3150
-
XIN6323
• 12 Volt, B-Circuit, IG-S-L-FR Terminals, 14.1 Vset
• Denso IR/IF Alternators
• Ignition activated
• Notes - Standard lamp function - no output.,Without LRC
• Replaces - DENSO 126600-3230
-
XIN6324
• 12 Volt, B-Circuit, F-L Terminals, 13.8 Default Vset*
• Denso IR/IF Alternators
• Notes - *Vset controlled by vehicle RVC system.
• Replaces - DENSO 126600-3240, 126600-3440
