XIN373
• 24 Volt, A-Circuit, D-IG-L Terminals, 28.4 Vset
• Denso IR/IF Alternators
• Ignition activated
• Notes - Active lamp function - with output.,D-terminal has no function.
• Replaces - DENSO 126000-3730
-
XIN429
• 12 Volt, A-Circuit, D-FR-IG-L Terminals, 14.5 Vset, w/ LRC
• Denso IR/IF Alternators
• Notes - Active lamp function - with output.,Similar to IN225 except: IN225: wo / LRC. IN429: w/ LRC.
• Replaces - DENSO 126000-1470, 126000-1471
-
XIN431
• 12 Volt, A-Circuit, C-FR-IG-L Terminals, 14.5 Vset
• Denso IR/IF Alternators
• Notes - Active lamp function - with output.
• Replaces - DENSO 126000-1410, 126000-1860, 126000-1880, HONDA 31150-P72-003
-
XIN433
• 12 Volt, A-Circuit, C-FR-IG-L Terminals, 14.5 Vset
• Denso IR/IF Alternators
• Notes - Standard lamp function - no output.
• Replaces - DENSO 126000-1360, 126000-1361
-
XIN434
• 12 Volt, A-Circuit, S-IG-L Terminals, 14.6 Vset, 5 sec. LRC
• Denso IR/IF Alternators
• Ignition activated
• Notes - Standard lamp function - no output.
• Replaces - DENSO 126000-0610, 126000-1440, 126000-1441, TOYOTA 27700-16010, 27700-50010, 27700-74010
